DEYE 15KW 48V HYBRID INVERTER - 3 PHASE
DEYE 15KW 48V HYBRID INVERTER - 3 PHASE - Image 2
DEYE 15KW 48V HYBRID INVERTER - 3 PHASE - Image 3
DEYE 15KW 48V HYBRID INVERTER - 3 PHASE - Image 4

DEYE 15KW 48V HYBRID INVERTER – 3 PHASE

SKU: A000412
Be the first to leave a review.

2 In Stock - More available on order

R46 000.00

Online Purchase Price, NOT Valid In-Store

2 In Stock - More available on order

Product Specifications

  • Model: SUN-15K-SG05LP3-EU-SM2
  • Type: Three-phase hybrid inverter
  • Battery Type: Lead-acid or Lithium-ion
  • Battery Voltage Range: 40–60V
  • Max. Charging Current: 280A
  • Max. Discharging Current: 280A
  • Number of Battery Inputs: 1
  • Max. PV Input Power: 24000W
  • Max. PV Input Voltage: 800V
  • MPPT Voltage Range: 160–650V
  • Rated PV Input Voltage: 550V
  • Start-up Voltage: 160V
  • No. of MPPTs / Strings per MPPT: 2 / 2+2
  • Rated AC Output Power: 15,000W
  • Max. AC Output Apparent Power: 16,500VA
  • Rated AC Output Current: 21.8A
  • Max. AC Output Current: 24A
  • Max. Continuous AC Passthrough (grid → load): 70A
  • Max. Efficiency: 97.6%
  • Euro Efficiency: 97.0%
  • MPPT Efficiency: >99%
  • Protection Functions: DC reverse polarity, AC output overcurrent/overvoltage, AC short circuit, thermal, DC component monitoring, insulation impedance detection, residual current detection, anti-islanding, DC switch, surge protection Type II (DC/AC), AFCI (optional)
  • Communication / Monitoring: RS485, RS232, CAN; GPRS / Wi-Fi / Bluetooth / 4G / LAN (optional)
  • Enclosure Protection Rating: IP65
  • Cooling: Intelligent air cooling
  • Noise: <60dB
  • Dimensions (W × H × D): 456MM × 750MM × 268.5MM (excluding connectors & brackets)
  • Weight: ±51.9kg
  • Warranty: 5 years

Product Features

The Deye SUN-15K-SG05LP3-EU-SM2 is a three-phase hybrid inverter delivering 15kW of power output for larger residential and commercial systems. With 24kW PV input capacity, dual MPPTs, and a wide voltage range, it maximises solar yield and ensures strong energy backup performance. A 280A charge/discharge capacity supports fast charging and reliable heavy-load operation.

Designed with transformer isolation and 100% unbalanced output capability, it allows up to 50% of rated power per phase, offering flexibility for uneven load conditions. Built with IP65 weather resistance, intelligent air cooling, and advanced protection features, the SUN-15K-SG05LP3-EU-SM2 is a durable and scalable solution for energy independence.

VIEW DATA SHEET

⚠️ Disclaimer

Installation must be done by a certified electrician in line with South African regulations. Incorrect installation may void the warranty.  Always follow manufacturer guidelines.
